WOODPECKER CUBE-180 | Solar Pathway Light

Model Name

CUBE-180

Luminous Flux

2,400lm

Solar Panel

56Wp MONO

LiFePO4 Battery

3.2V 36AH

Warranty

5 Years

Send inquiry

More info

The WOODPECKER CUBE-180 is a compact vertical solar pathway light designed to balance architectural form with reliable outdoor performance. Its clean four-sided aluminum alloy structure integrates vertical solar panels with a wood-inspired finish, allowing the fixture to blend naturally into pathways, parks, residential landscapes and other outdoor spaces.<br /><br />Equipped with a 12W high-efficiency LED system delivering up to 2,400lm, the CUBE-180 combines 56Wp mono solar panels with 23.5% cell efficiency and a long-life LiFePO4 battery. A microwave motion sensor and multiple remote-control modes support intelligent lighting operation, while IP65 and IK08 protection provide durability for long-term outdoor use.

Key Componente & Advantages

Vertical Solar Panels

Capture sunlight from multiple angles for improved energy generation.

High Brightness LED

200lm/W high-efficiency LED delivers powerful illumination with low energy consumption.

23.5% Cell Efficiency

High-efficiency mono solar cells improve energy conversion within a compact vertical design.

Long-Life LiFePO4 Battery

4,000 cycles at 80% D.O.D provide reliable energy storage for long-term operation.

Microwave Motion Sensor

Detects movement and automatically adjusts brightness to reduce unnecessary energy use.

Multiple Modes Remote Control

Built-in lighting programs allow flexible mode selection and brightness adjustment.

IP65 & IK08 Protection

Engineered with IP65 ingress protection and IK08 impact resistance for reliable outdoor use.

Anti-Corrosion Coating

Protective surface treatment enhances durability for long-term outdoor environments.

Wood Bionic Texture

Natural wood-inspired texture allows the fixture to integrate elegantly into surrounding landscapes.

Main Specification

Model Name

CUBE-180

Dimension

160*160*1100mm

Max LED Power

12W

Luminous Flux

2,400lm

A.o.o

500~1000lm

LED Chips

SMD5050 5W/LED max

LED Lifetime

100,000H

CRI

Ra ≥70

CCT

2200K / 3000K / 4000K / 6000K

Solar Panel

56Wp MONO

Cell Efficiency

23.5%

Solar Panel Lifetime

>20 years

Battery Capacity

3.2V 36AH

Battery Lifetime

4,000 cycles D.O.D 80%

IP & IK Rate

IP65 IK08

Material

Aluminum Alloy

Fixture Color

wood / Black / Customized

Motion Sensor

Microwave

Warranty

5 Years

Main Specification

Model Name

Dimension

Max LED Power

Luminous Flux

A.o.o

LED Chips

LED Lifetime

CRI

CCT

Solar Panel

Cell Efficiency

Solar Panel Lifetime

Battery Capacity

Battery Lifetime

IP & IK Rate

Material

Fixture Color

Motion Sensor

Warranty

CUBE-180

160*160*1100mm

12W

2,400lm

500~1000lm

SMD5050 5W/LED max

100,000H

Ra ≥70

2200K / 3000K / 4000K / 6000K

56Wp MONO

23.5%

>20 years

3.2V 36AH

4,000 cycles D.O.D 80%

IP65 IK08

Aluminum Alloy

wood / Black / Customized

Microwave

5 Years

Download

Data Sheet

User Manual

Certificate

Datasheet of WOODPECKER CUBE-180

*.pdf

Download

User Manual of WOODPECKER CUBE-180

*.pdf

Download

You May Ask

What's the material of solar bollard?

Auroras's solar bollard light heads adopt UV-resistant polycarbonate which is anti-vandal and of high transparent performance., Pillar is made of aluminum alloy.

What's the default working mode of solar bollard?

2h 100% +5h (30%+70% sensor)+6h (10%+40% sensor)

Which solar bollard lights reach IK10?

ARKO/MUSE/LETO/HESTIA/ATLAS

Which solar bollard light has IDA certification?

MUSE and LETO are IDA approved.

Is easy to replace the battery part?

All connections of components insides are using plug&play connectors, The battery can be easily replace / repaired with minimal time.

What is the thickness of the pole of Atlas?

The thickness is 6mm which is very strong and robust.

Could solar bollard lights increase battery capacity?

Some models of solar light can use bigger capacity battery, while 38.4WH battery is indeed very sufficient for low power consumption light, so normally we prefer to keep it as it is.

Which solar bollard light can use the battery capacity?

ARKO, MUSE, LETO, HESTIA

Can you change the powder coating color of fixture?

Yes, MOQ 100pcs per item.

10.

Do you accept OEM orders?

Yes, OEM is welcomed with MOQ 100pcs/item.
