cylindrical solar module
  • cylindrical solar module
  • cylindrical solar panel
  • cylindrical solar led street post
  • solar cylinder module
  • vertical solar module

Detachable Vertical Solar Module

Q100 as 100W cylindrical solar module is an perfect module to be used for 20W 30W solar led street light, It adopts high quality MONO cell with efficiency up to 21.3%. You can also easily get 200W,300W 400W..etc with multiple 100W solar panels in parallelled connection.
Model:Q100 丨Q140 丨Q200 linkable
Peak power / Pm(W) 140W 200W
Voltage/Current 18V 7.78A 36V 5.56A
Cells efficiency >21.5% >21.5%
Max pole diameter 155mm 155mm
Dimension 200*228*1560mm 200*228*2060mm
N.W/G.W 21.30kg/22.80kg 25.30kg/27.80kg
What is vertical solar street light

Vertical solar LED street light pole is an great innovation with latest technology. It adopts the vertical solar modules by surrounding the pole instead of regular solar panel installed on top.  Comparing with traditional solar led street light, it has a very cosmetic appearance in the same look as traidional street light.

Each vertical solar module adopts 6 pieces of slim mono-crystalline solar panel with high efficiency up to 21.2% and more than 20 years lifetime. Each slim solar panel are 18V/36V and 6 pieces slim solars are connected together in parallel connection.  Each vertical solar module contains two modules as master module which has 2 pairs of MC4 connectors and sub-module with 1 pair of MC4 connectors.  As the big part of vertical solar led street light, the vertical solar module is designed based on the modular conception which is supposed to be installed on any shape and new or old poles as customers requre.  And customer can freely combine different powers of solar panel according to the power consumption by series connection. for example 280W,300W,420W,500W,700W etc.

Retrofit of traditional street lights

There are huge numbers of traditional street light in everywhere, and these light bulb are metal halide or halogen, all of those light bulb are old technology and power consumptions are very high while the lighting efficiency is very low. As the energy shortage globally are getting worse, all of these old traditional lights are supposed to be retrofited by led and solar energy technology in order to reduce the energy consumption to build up a green earth.
Auroras's vertical solar solution is an perfect answer to meet this requirements. It can retrofit the old lights without replacing the poles, and no need to dig holes on ground for battery or attach the battery box on pole if adopt all in two solar light heads. It reduce the cost of retrofit work in labor cost, pole cost etc greatly and keep light pole almost same appearance as before.

retrofit of traditional street light
street light retrofit
Videos on YouTube
1 : Introduction of vertical solar module and retrofit solution.
2 : installation on site in Phillipines 2019
Key advantages
Key Specification of Vertical Solar Module
Model number Q140 Q200
P.max 100 Watts 200 Watts
Vmp 18V 36V
Imp 5.56A 5.56A
Dimension 1160*228*200*mm 2060*228*200mm
N.G / G.W 21.50 /22.80 kg 25.30 /27.80 kg
Cable & connector 2.5mm2 with MC4
Solar cell efficiency 20.50%
Solar cell type MONO cell
Structure material Aluminium alloy
Working temp. -30℃~+70℃
Warranty 5 years
Life time >20 years
Patented Products Yes
Certificates CE, ROHS, IP65
vertical solar led street light
PV Dimension
Configuration Recommended of Vertical Solar Street Light
30w vertical solar street light
Order Code VST03020005
Light power 30W
Luminous flux >4,200lm
Battery pack 12.8V 307WH
Vertical PV 18V 200W
PV module 1pc Q200
Pole height 5 meters
Lifetime >8 years
Warranty 3 Years
50w vertical street light
Order Code
Light power
50 Watts
Luminous flux >6,500lm
Battery pack 12.8V 460WH
Vertical PV 5.56A
PV module 2pcs Q140
Pole height 6 meters
Lifetime >8 years
Warranty 3 years
dual solar light head vertical street light
30W*2 -Dual
Order Code VST03040008
Light power 30 Watts 2pcs
Luminous flux >4,200lm
Battery pack 307WH 2pcs
Vertical PV 340W
PV module 2pcs Q200
Pole height 8 meters
Lifetime >8 years
Warranty 3 years
80w 8m vertical solar led street light
Order Code VST08040008
Light power 80 Watts
Luminous flux >12,800lm
Battery pack 768WH
Vertical PV 36V 400W
PV module 2pcs Q200
Pole height 8 meters
Lifetime >8 years
Warranty 3 years
10m vertical solar street light 100w
Order Code VST2060010
Light power 120 Watts
Luminous flux >15,800lm
Battery pack 1075WH
Vertical PV 36V 600W
DPV module 3pcs Q200
Pole height 10 meters
Lifetime >8 years
Warranty 3 years
dual heads vertical solar led street light
80W*2 Dual
Order Code VST08080012-D
Light power 80 Watts 2pcs
Luminous flux >12,800lm
Battery pack 768WH 2pcs
Vertical PV 36V 800W
PV module 4pcs Q200
Pole height 12 meters
Lifetime >8 years
Warranty 3 years
Project Reference
vertical solar led street light
vertical solar led street light pole
vertical solar pole light
vertical solar pole light
Marketing Feedback

As an memorable innovation in solar led street light industry, This modular vertical solar module has a huge demand for many potentical applications, for example retrofit of traditional street light,traffic light and signals, Auroras vertical solar light are getting more and more attention globally from many valuable customers.

in 2021. Auroras provided the SolarWrap vertical solar street light to Dubai Expo. More and more clients are getting interested in this new solar lighting design. Vertical solar led street light is the ideal solution for high-end projects with many benefits.

Intellectual Property

The designs of vertical solar module are registered in China patent database. Any copy or imitation will be be held accountable with being infringement.Any attempt to purchase from the imitation factory may face confiscation by the customs and pursue related losses.

Projects Cases
@ New Zealand
@ New Caledonia
@ Philippines
Pre :  Vertical Solar Street Lights
Next :  Vertical Solar Garden Pole

You may ask

  • 1.What type of solar cell do you use for solar cylinder module?

    The solar cell is MONO in PERC technology, It has a higher power and efficiency than flexiable solar module, Auroras's SolarWrap is more economical and more pratical to be used for projects with bulk quantity
  • 2.Can i order a sample to test? And how soon will you send it?

    Cylindrical solar module is a very popular products since Feb of 2019, Every day we are producing it, Even you only need 1 or 2 pcs, We can arrange immedately and send to you in time. Normally we only 2~3 days to send once we get your payment information.
  • 3.Can i purchase your cylindrical solar module only without light or pole?

    The answer is positive, Auroras is willing to provide only solar cylinder module as a seperate product. you can use it for your own way for other application.  There are two models availble . One is 100W and the other is 140W.  We can customize the power if you a different size. MOQ is 50 Units.
  • 4.What is the max power of vertical solar panel?

    The max power of cylinder solar module is 140W. while you can get higher powers easily as you like. Each vertical solar panel has two pairs of MC4 connectors, one pair is for input,and the other pair is for output. With 100W and 140W options, you can easily get 200W, 280W 300W,420W,560W etc in series connection. Every two modules are connected to each other by MC4 universal plugs.  Max 7 pcs can be connected in one system.
  • 5.Do you provide OEM service

    Yes, Auroras believe the fastest and the most efficienct way is to cooperate with all greatest customers based OEM business. With that Auroras is able to provide a good products under the customers' reputation which is impossible to be build up with short time.   So Auroras prefer to use your ready marketing channels and just let auroras's products running there. OEM are welcomed. :)
  • 6.Can i connect 3~5 cylinder panel in series connection

    Yes, Each solar cylinder panel has input and output cables with MC4 plugs, you can connect 2~5 modules in series connection to get higher power depending on lighting power consumption. Please note you must use the MC4 adapters between every 2 modules.
